Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual 99
Easy Mode (Pre‐Defined Setups) LeCroy Corporation
Analyzers work with Emulators, Jammer, and Trainer (see below).
One Initiator Emulator can work by itself or work with one Analyzer.
One Target Emulator can work by itself or work with one Analyzer.
(Note that Host Emulator and Analyzer can be on one port and
Analyzer and Device Emulator can be on another port at the same time.)
Emulators do not work with Trainer.
Emulators work with Jammer (see below).
Note: Ports 1 and 2 are a pair, and Ports 3 and 4 are a pair. Put related hardware on one pair. For
example, put two analyzers on ports 1 and 2, and two emulators on 
Ports 3 and 4.
Jammer can pair with one or two analyzers on a port. 
Jammer can go on the other pair from the analyzers pair. 
Jammer can go on the other pair from the emulators pair or analyzers/emulators pair.
Jammer does not work with Trainer.
Project Number
Target Emulator Port 1.
Pair on Port 1
One emulator each
on
Port 1 and Port 2.
One emulator each
on
Port 1 and Port 3.
One emulator each
on Port 1 and 2 and
one analyzer each on
Port 3 and 4.
One analyzer each on
Port 1 and 2 and
one emulator each
on Port 3 and 4.
Pair on Port 1 and
pair on Port 2.
Pair on Port 1 and
pair on Port 3.
Pair on Port 1 and
one analyzer each on
Port 3 and Port 4. One each on
Port 1, 2, 3, and 4.
