LeCroy Corporation Setting Up for Generating Initiator Traffic
376 Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
Setting Up for Generating Initiator Traffic
Connect the SAS cable from the Target port of the Sierra Analyzer to the Target port on
the unit under test. This transmits the Traffic Generator stream from the Target port to
the target‐side port on the unit under test.
Setting Up for Generating Target Traffic
Connect the SAS cable from the Initiator port of the Sierra Analyzer to the 
Initiator‐side port on the unit under test. This transmits the Traffic Generator stream from
the Initiator port to the initiator‐side port on the unit under test.
Creating a Traffic Generation File
Generating traffic is a two‐step process.
First, create a text‐based Sierra Trainer Traffic Generator file. This text file has an .ssg
extension. You can create this file by creating a new generator file or editing an existing
file.
Note:
.ssg files created in other applications run in the Sierra Trainer.
After the file has been created, it can be opened and displayed in the application. You can
invoke the application to transmit the traffic generation file by using the Start Generation
button .
Note: For details about traffic generation files, see “Sierra Trainer Generation Language” on page 392 .
