Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual

209

Switching Views

LeCroy Corporation

Data Payload View

To display the Data Payload View, double‐click a data payload field in a Packet or
Spreadsheet view, or right‐click a data payload field and select Open as Data View:

Figure 3.38: Data Payload View

Note:

When showing truncated data in the Data Payload View, the truncation points are marked with

a separator placed between payloads. You can get more information about the data exclusion
using the tooltip over the separator.

Note:

You can control the number of bytes per line.

Find Data Pattern

To quickly locate a data pattern in the current frame, enter the pattern in the Text Box and
click the Find button.
