Generating Traffic LeCroy Corporation
Generating Traffic
After the .ssg file has been opened onscreen, recording and traffic generation can begin
at any time.
1. (optional) Click to begin the recording.
2. If the script does not have a connect block built into it, connect the exerciser to the
DUT by clicking the Connect Link button . Clicking this button causes the
generator to invoke the various settings in your script (for example, the global
settings) and then establish a connection.
3. Click the Start Generation button on the Toolbar.
While generating traffic, a bar appears on the right of the trace view, indicating that traffic
generation is taking place. (The green light on the Traffic signal button also blinks during
traffic generation).
Stop Traffic Generation
Normally, traffic generation stops automatically when the application reaches the end of
the Generator file.
To manually stop traffic generation, click the Stop Generation button .
Resume Traffic Generation
If traffic generation is stopped prior to the end of the script, it can be resumed.
To resume traffic generation, click the Resume Generation button .
