LeCroy Corporation Scenario Events
326 Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
While many events are line conditions, an event also can be a condition that occurs
within a InFusion device (for example, detection of a trigger signal from another device). 
The following table lists supported events. Note that some events are applicable only in
the context of creating sequences (those events appear on the drop‐down list only if you
are creating a sequence). Sequences can have multiple states, and they allow branching
between states.
TABLE 4.2: Events
The following sections provide some additional details about three of the above events.
Event Description
Address Frame Occurrence of a specified address frame.
Analyzer Trigger Trigger on Analyzer when its event matches. You can see the
trigger on the Status Bar, but the Port Status dialog does not
display any mark in the Trigger column.
Note: This is different than the external trigger mechanism.
You do not need an external trigger cable.
Any DWORD Occurrence of any DWORD.
ATA Command Occurrence of a particular ATA command.
ATA Command Frame Occurrence of a particular ATA command frame.
[+] ATAPI Occurrence of a particular ATAPI command from the list:
MMC4, RBC, SBC2, SMC2, SPC2, SPC3, or SSC2.
Both Links Up Occurrence of both line ports active (not idling).
CRC Error Occurrence of a CRC error.
DWORD Matcher Occurrence of a particular DWORD.
FIS Frame Occurrence of a particular FIS frame.
FIS Type Occurrence of a particular SATA FIS type.
Frame Type Occurrence of a particular frame type.
Invalid 10bit‐code
Error Occurrence of an invalid 10b code.
Links Speed 3G Both lines operating at 3 Gbps.
Links Speed 6G Both lines operating at 6 Gbps.
OOB Signal Occurrence of OOB signal.
[+] Primitives Occurrence of Primitive Group, SAS Primitive, or SATA
Primitive.
Running Disparity Error Occurrence of Running Disparity (RD) error.
SAS Data Pattern
Occurrence of a particular data pattern in a SAS frame.
SATA Data Pattern Occurrence of a particular data pattern in a SATA frame.
{+} SCSI Occurrence of a particular SCSI command from the list:
MMC4, RBC, SBC2, SMC2, SPC2, SPC3, or SSC2.
SMP Frame Occurrence of a particular SMP frame.
SNW Occurrence of Final SNW, SNW1, SNW2, SNW3, Train SNW
SSP Frame Occurrence of a particular SSP frame.
Timer Occurrence of a particular elapsed time (time period).
Trigger Input Occurrence of input trigger.
