TCP and UDP Ports Must Be Open to Connect over Ethernet LeCroy Corporation
TCP and UDP Ports Must Be Open to Connect over Ethernet
WARNING: Check your firewall settings before making Ethernet connections. Incorrect
firewall settings can prevent LeCroy applications from detecting analyzers on
the network, though Ping works correctly. Consult your Firewall
documentation to allow LeCroy applications to the network.
The following TCP and UDP ports must be open to connect over the Ethernet:
 TCP Port: 4000 to 4003
 UDP Ports: 4015 to 4017
Launching Your Analyzer
To launch the software, double‐click the SAS or SATA Icon in the Program Manager
Window.
Operating in Simulation Mode
Your system operates in the Simulation Mode by default if the hardware is not detected.
However, you may operate in Simulation Mode directly without installing the Analyzer
hardware. To operate without hardware, select Hardware Not Installed (Simulation
Mode) in the Port Setting dialog box and click OK.
The Analyzer software launches and displays the appropriate tool bar, but with the
limitation that the Analyzer operates only on static, previously captured, bus data.
Limitations The Simulation mode lets you try all of the available functions, but
keep in mind that the system is not capturing any real data and is
displaying only pre‐captured results.
Using the Software
The Sierra M6‐4 application has the LeCroy SAS Protocol Suite and the
LeCroy SATA Protocol Suite.
The LeCroy SAS Protocol Suite can be a:
 Protocol Analyzer: Captures data, triggers on events, and saves. Easy Mode
allows standard Trigger and Data capture. Advanced Mode (requires license)
allows you to program custom triggering in and out, capturing, state jumps, and
timers (
See “Protocol Analysis” on page 43 ).
 Protocol Analyzer Initiator Emulator: Generates bus traffic for capture. It also
has Easy Mode and Advanced Mode (
See “Exercise and Capture” on page 110 ).
 Target Emulator: Acts as target ( See “Target and Device Emulation” on
page 162 ).
The LeCroy SATA Protocol Suite can be a:
 Protocol Analyzer: Captures data, triggers on events, and saves. Easy Mode
allows standard Trigger and Data capture. Advanced Mode (requires license)
allows you to program custom triggering in and out, capturing, state jumps, and
