LeCroy Corporation Creating a Sequence
348 Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
By default, the name of the first sequence in a scenario is Sequence 0. The name of the
first state is State 0. To change the name of a sequence or state, or to associate a
description with it, click the name of the sequence or state. A dialog box appears that
allows you to enter that information.
Note: The description does not appear on screen, but you can bring it up by clicking the name of the
sequence or state.
4. In the State 0 area, click the prompt to add an event.
Figure 4.40: Example 7: Adding an Event for the First State
The Event Properties dialog box appears.
5. In the Event Properties dialog box, select Address Frame as the event.
6. Click OK to close the Event Properties dialog box.
