LeCroy Corporation Display Configuration
254 Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
 Two port configuration (AA ‐ ‐): If you use manual stop,
Memory Assignment has no effect. Sample size depends on port traffic
loads.
 Two port configuration (AA ‐ ‐): If trigger is set at 50%, and there is enough
data to fill pre‐trigger, Memory Assignment has an effect. Sample size is typi‐
cally near specified size.
 Two port configuration (AA ‐ ‐): If trigger is set at 50%, but there is not
enough data to fill pre‐trigger, Memory Assignment has an effect. Sample
size is typically more than half specified size, with size determined by the
amount of data captured before trigger.
 Two port configuration (A ‐ A ‐): Ports 1 and 3 are not on the same FPGA, so
Memory Assignment has no effect. If one port has heavy traffic, it may fill its
memory bank and stop recording, resulting in smaller sample size than spec‐
ified.
Note: Checking this option does not affect the sample. It only allows larger sample sizes.
Note: If traffic is balanced on ports, sample size is the same whether you check or uncheck the
Sampling Memory Usage Optimization option.
Note: Memory Assignment depends on traffic load distribution at the time when the system tries to
re‐assign physical links to memory banks. Therefore, if you repeat a capture with the same
Sampling Memory Size and Segment Number parameters, the resulting sample size may not be
the same. However, if traffic load distribution is similar, sample size will be similar.
Note: The buffer status indicator shows buffer by FPGA, not by port.
If the Sampling Memory Usage Optimization Option is Not Checked
Each physical link (or logical link if MUX is enabled) is assigned to a specific memory space
(memory bank), depending on the Sampling Memory Size and Segment Number
parameters.
Important: If any physical link fills its memory bank, the recording process stops. Other
memory banks will typically be less than full (and can be empty). The sample file might be
smaller than the user‐defined Sampling Memory Size. You might even think that the
Analyzer malfunctioned.
