Sierra Trainer Generation Language
LeCroy Corporation
Wait Command Groups
WF_PS_REQ_SLUMBER
primitive
WF_PS_ACK
primitive
WF_PS_NAK
primitive
Wait Command Group
Group Contents
WF_TIMEOUT
WF_TIMEOUT_BLOCK_ONE
WF_TIMEOUT_BLOCK_TWO
WF_ALL_SOF
WF_SOF
WF_SOAF
WF_ALL_EOF
WF_EOF
WF_SOAF
WF_NAK
WF_NAK_CRC_ERROR
WF_NAK_RESERVED_0
WF_NAK_RESERVED_1
WF_NAK_RESERVED_2
WF_RRDY
WF_RRDY_NORMAL
WF_RRDY_RESERVED_0
WF_RRDY_RESERVED_1
WF_CREDIT_OK
WF_CREDIT_AVAIL
WF_CREDIT_BLOCKED_RECEIVED
WF_CLOSE
WF_CLOSE_CLEAR_AFFILIATION
WF_CLOSE_NORMAL
WF_CLOSE_RESERVED_0
WF_CLOSE_RESERVED_1
WF_DONE
WF_DONE_ACK_NAK_TIMEOUT
WF_DONE_CREDIT_TIMEOUT
WF_DONE_NORMAL
WF_DONE_RESERVED_0
WF_DONE_RESERVED_1
WF_DONE_RESERVED_TIMEOUT_0
WF_DONE_RESERVED_TIMEOUT_1
