LeCroy Corporation Primitive and Frame Definitions
384 Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
Primitive and Frame Definitions
Five other Include files are provided that define the most of the known templates for
Primitives and Frames. The five are:
 PrimitivesDecl.inc
 AddressFramesDecl.inc
 SSPFramesDecl.inc
 SMPFramesDecl.inc
 STPFramesDecl.inc
Each of the Frame templates defines header and field structure.
The default value for all Frame fields is zero.
Special Conditions for Frames
There are three conditions about Frames that need to be kept in mind when configuring
Frame generation:
1. Frame delimiters need to agree ‐ At the present time, when defining a Frame, make
sure that the Frame Prologue and Frame Epilogue agree. Do not mix types. For example,
do not mix a SAS Start of Frame (SOF) with a SAS End of Address Frame (EOAF).
A SAS SOF should be matched to a SAS EOF. A SAS SOAF should be matched to a SAS
EOAF. If generating SATA traffic, a SATA_SOF should be matched to a SATA_EOF.
At the present time, if you mix different types of prologues and epilogues for any given
Frame, the Frame is ignored.
2. Data Length Fields can be fixed‐length or variable ‐ By default, data frames are of a
fixed length. If you want to generate variable length frames, place an asterisk in the Data
definition field in the SSPFramesDecl.inc file: 
Data : *
If you replace the asterisk with a value, then the field becomes fixed length.
3. CRC Calculations are calculated unless told otherwise ‐ If the CRC is not explicitly set
in the traffic generation file, the application assumes that you want it and calculates and
displays it in front of the generated frames.
If you provide a CRC value, the application uses that value, even if it is incorrect. This
gives you the option of configuring the generator to create errors.
If the generation file was created through the Export command (File > Export > To
Generator File Format ...), the CRC is calculated but commented out. If the source trace
has a bad CRC, the CRC is exported into the generation file and is not commented out.
