261
Video Layout
EDIUS - Reference Manual
1 Select a clip, and start up layouter.
Set the key frame on the timeline in layouter.
(1) Timeline controller Drag the slider to the left and right to adjust the time scale display unit. Move
the slider to the left to reduce the display unit, or to the right to increase it.
The right end is [Fit].
(2) Time scale settings Click this to toggle the specified display unit and [Fit].
Click the left arrow to reduce the display unit, or click the right arrow to
increase the display unit.
(3) Playback/Tool
buttons
: Play back the timeline on the Recorder.
: Repeatedly play back the clip currently being edited.
: Undo an operation.
[Ctrl] + [Z]
: Redo the undone operation.
[Ctrl] + [Y]
: Switch the changes of each parameter to the chart view. In the chart
view, the timeline is represented by a chart display of the selected key. The
parameters can be edited by moving the keys up and down.
The numerical values and gradations of the Y axis can be changed by
entering numerical values.
(4) Time scale for key
frame Display a scale with the unit selected in the time scale setting on the timeline.
Right-click the time scale and click [Timeline Timecode] to display the
timecode of the timeline or click [Zero base Timecode] to display the
timecode with the beginning of the clip as 0.
If a sequence marker is set for the position where the clip is placed,
right-click the time scale and click [Go to Previous Sequence Marker] or [Go
To Next Sequence marker] to move the timeline cursor to the previous or
next sequence marker.
(5) Enable/Disable Unchecking the item disables the parameter settings. To set a key frame,
check [Layouter].
(6) Expand button Click this button to configure detailed settings for each item.
The layout can be edited by entering a numerical value or moving the mouse
to a control and dragging when the mouse cursor changes shape.
(1)(2) (3) (4)
(5)
(6)
(8) (9)
(7)
