Timeline Settings
EDIUS - Reference Manual
Timeline Settings
Track Display
The following explains the descriptions of the track header and the types of tracks.
Track Header
You can make settings for each track simply on the track header, for example, to lock the track for preventing placed
clips from moving or to set the track to exclusively play back audio.
You can set the following items in the track header.
(1) Track patch When a clip is displayed on the Player or a clip is selected in the bin, the
channel held by that clip (source channel) is displayed on the track patch.
When a clip in the source browser is selected, the source channel is
displayed on the track patch according to the channel map in the project
settings. Also, the track patch position displays which track the source
channel is mapped to when a clip is placed on the timeline by a shortcut key
or button. The source channel mapping to each track can be changed.
Setting Channel Mapping 0 P225
(2) Track panel Click this to switch the select/deselect setting for the track.
(3) Batch lock panel Click this to set sync-lock for all tracks on and off.
Sync-lock (Synchronization) 0 P219
Right-click to lock the selected track.
Locking Tracks 0 P214
(4) Audio expand button Click this button to display the rubber band for the audio.
[Alt] + [S]
(5) [Video Mute] When mute is set, the video part of the track is not played back. The video
part and mixer area of the clip on a muted track is displayed in gray.
[Shift] + [W]
(6) [Audio Mute] When mute is set, the audio part of that track is muted. The audio part and
volume/pan part of the clip on a muted track is displayed in gray.
[Shift] + [S]
(7) [Volume/Pan] Switch between the volume adjustment mode and the pan adjustment mode.
Adjusting the Volume and Pan of a Clip 0 P399
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
