HĆ4 800 Series Operator's Manual
Figure HĆ2.āăInstalling the Voltage Bobbin
Power Input
Fuse Compartment Door
Air Filter Cover
Fuse Compartment
Door Notch
Voltage Selection
Bobbin Window
Voltage Bobbin
100 VAC
120 VAC
e. Check the system fuses.
f. Pull one of the fuse holders out of the fuse compartment, as shown in
Figure H-3.
Figure HĆ3.āăInstalling the System Fuses
Fuse
Fuse Holder
Fuse compartment
door in open position.
Voltage Selection
Bobbin
Fuse Compartment
