1Ć28 Rapidlab 800 Operator's Manual
Sensor icons appear in the status area of the screen. Each sensor is represented by a
box containing the sensor label. The CO-ox module is represented by the tHb icon
in the sensor bar. The sensor icons indicate the current status of each sensor
installed on the system.
If the sensor icon is . . . Then the sensor is . . .
a green box with
black text turned on and in calibration.
a yellow box with
black text and a slash
across the label turned on but out of calibration.
not visible turned off or not installed.
Using the Analyze Mode
The Analyze mode is the operating mode where you perform the most frequently
required functions. When the system is ready to analyze samples, the Ready screen
appears with the Begin Sample Analysis message box. The F-key labels shown
below appear at the bottom of the Ready screen.
Press Change
Parameters to select
specific parameters for
analysis.
Press Menu to access
the Menu mode. Press Calibrate to
select a manual
calibration.
Press Change Sample
Type to select a different
sample type for analysis.
