EĆ8 800 Series Operator's Manual
Table E-8 lists the units, reporting ranges, and display resolutions for the
parameters that can be entered into the 800 system.
Table EĆ8.āăEntered Parameters
Parameter Units Reporting Range Resolution
Temperature
_C
_F
10.0 – 43.9
50.0 – 111.0*
0.1
0.1
F
I
O
2
%
decimal
fraction
15.0 – 100.0
0.150 – 1.000
0.1
0.001
ctHb g/dL
g/L
mmol/L
2.0 – 27.0
20 – 270
1.3 – 16.8
0.1
1
0.1
OBF 1.35 – 1.40 0.01
Flow L/min 0.00 – 99.99 0.01
Resp Rate b/min 0.0 – 100.0 0.1
p50 mmHg
kPa
15.0 – 75.0
2.00 – 10.00
0.1
0.01
Qt L/min 0.00 – 30.0 0.01
* The 800 system converts Fahrenheit values to centigrade values.
