4Ć81
Troubleshooting the System
Figure 4Ć15.ā Removing Obstructions from the Sample Port
Capillary Seal
Drip Tray
Sample Door
Retainer Ring
Sample Port
Clot-removal Line
Mount
O-ring
7.
Inspect the mount for obstructions and clean if necessary.
8.
After removing any obstructions, reinstall the sample port:
NOTE:ĄĂ
Ensure that the three O-rings are in place on the mount.
a. Reinstall the sample port onto the mount, matching the tab on the sample
port to the notch in the retainer ring.
b. Grasp the tab on the retainer ring and turn the retainer ring away from you
to lock it in place.
c. Replace the sample door, and ensure that it snaps into place.
9.
Press
Continue
.
A wash sequence starts. When the wash sequence finishes, a message box
appears prompting you to perform a two-point calibration.
10. Press
Yes
to perform a two-point calibration.
11. Analyze QC material as necessary to verify sensor performance.
