Page 380
4Ć92
800 Series Operator's Manual
Disconnecting the COĆox Sample Path
Use this procedure to disconnect the CO-ox sample path from the base model. You
can continue to measure the remaining parameters.
BIOHAZARD:
Refer to Appendix A, Protecting Yourself from Biohazards, for
recommended precautions when working with biohazardous materials.
1.
Turn the CO-ox parameters off:
a. Select
6 System Setup
and press
Enter
.
b. Select
3 Parameters
and press
Enter
.
c. Move to the CO-oximetry frame.
d. Select the tHb parameter and press
Enter
.
This turns all CO-ox parameters off.
e. Press
Next Screen
to access the second screen of parameters.
f. Press
Next Screen
to access the third screen of parameters.
g. Press
Done
when you finish.
2.
Disconnect the CO-ox and base model sample tubing from the sample
connector.
3.
Remove the screw from the sample connector.
4.
Invert the sample connector so that the “Y” is on the bottom as shown in
Figure 4-21.
Figure 4Ć21.ā Disconnecting the COĆox Sample Path
Preheater
Sample Connector
Inverted
Connector
6
Menu Code
3
