3Ć50 Rapidlab 800 Operator's Manual
6. Ensure that the O-ring is in place. Replace the O-ring if it is worn or damaged.
CAUTION: Do not remove or return the sensors to the measurement module
without first discharging static buildup. Touch the inner surface of the module
frame to discharge static buildup.
NOTE: If the sensor does not insert easily into the measurement module, slide the
remaining sensors to the right to create more space.
7. Reinstall the sensor:
a. Gently align the top of the sensor with the sensor contact.
b. Snap the body of the sensor down into place.
c. Press the tab on the spring-loaded latch to release the latch.
8. Close the measurement module door.
9. Press Continue .
A wash sequence starts. When the wash sequence finishes, a message box
appears prompting you to perform a two-point calibration.
10. Press No .
11. Allow the system to warm up for at least 15 minutes.
12. Check the sample path temperature from the Menu screen:
a. Select 3 Troubleshooting and press Enter .
b. Select 2 Temp/pAtm and press Enter .
c. Press Start Test .
d. Press Stop Test .
e. Check the screen for the sample path temperature.
f. If the temperature control system is off, press Reset Control .
g. Press Exit Test .
13. Perform a two-point calibration from the Menu screen:
a. Select 1 Calibration and press Enter .
b. Select 2 Two-point and press Enter .
!
3
Menu Code
2
(from the Main Menu)
1
Menu Code
2
(from the Main Menu)
