3Ć34
Rapidlab 800 Operator's Manual
Replacing the Measurement Module Tubing
Materials required:
S measurement module tubing
BIOHAZARD:
Refer to Appendix A, Protecting Yourself from Biohazards, for
recommended precautions when working with biohazardous materials.
NOTE:
If your system has a CO-ox module, follow the procedure described for
the appropriate base model. For example, information identified for an 860 also
applies to an 865.
1.
Cut a piece of measurement module tubing to the appropriate length as shown
in Figure 3-19.
Figure 3Ć19.āăMeasurement Module Tubing Length
System
Tubing Length
840
15.2 cm (6 inches)
850
12 cm (4.75 inches)
860
11.43 cm (4.5 inches)
2.
Stop the system from the Menu screen:
a. Select
2
Maintenance
and press
Enter
.
b. Select
7 Stop System
and press
Enter
.
3.
Push up the latches on the measurement module door and lift the door.
4.
Take the appropriate action.
If you have an . . .
Then continue with . . .
840
step 5.
850 or 860
step 6.
2
Menu Code
7
