800 Series Operator's Manual
5Ć58
1.
Access the Calibration Drift Limits screen from the Menu screen:
a. Select
5 Operating Setup
and press
Enter
.
b. Select
6 Calibration Setup
and press
Enter
.
c. Select
1
Drift Limits
and press
Enter
.
The Calibration Drift Limits screen appears, as shown in Figure 5-35.
Figure 5Ć35.ā Calibration Drift Limits Screen for an 850
Press Clear Entry to
delete text in a field.
2.
Move to the field that you want to change.
NOTE:ĄĂ
The number you enter establishes a range above and below the
expected value. For example, if you enter 2 as the drift limit, the range is plus
or minus 2 from the expected value.
3.
Type the new drift limit and press
Enter
.
4.
Repeat steps 2 and 3 for each parameter for which you want to enter or change
the drift limit.
5.
Press
Done
when you finish.
6.
You can define another setup function or press
Exit Menu
to return to the
Ready screen.
If you type an invalid value in a field and press Done, the Invalid Entry message
box appears. Press
OK
and type a valid entry in the field.
Defining Calibration Gas Values
Use this procedure to define the calibration gas values for the gases used during
calibration. Table 5-23 lists slope and cal ranges for
p
CO
2
and pO
2
.
1
6
Menu Code
5
Procedural
Notes
