3Ć76 Rapidlab 800 Operator's Manual
Figure 3Ć49.āăRemoving the Reservoir Cap with the Hex Tool
Hex Tool
Reservoir Cap
OĆring
OĆring
Sample Path
KCI Reservoir
Vent Hole
b. Partially fill the KCl reservoir as shown in Figure 3-50.
Figure 3Ć50.āăFilling the KCl Reservoir
4M KCl Fill Solution
Fill Line
OĆring
OĆring
Sample Path
Electrode
Compartment
c. Tap the front face of the sensor with your knuckle to release any bubbles.
d. Gradually fill the KCl reservoir with KCl fill solution up to the fill line.
CAUTION:ĄĂ Do not overtighten the reservoir cap. Overtightening can deform
the gasket and cause leaks.
e. Reinstall the reservoir cap and hand tighten.
10. Continue with Reinstalling a Sensor , page 3-89.
!
