System Administration 5Ć13
Figure 5Ć5.ā Parameters Screen for an 850 system
Select the parameter
panel you want.
Press Next Screen to view
additional parameters.
2. Select the parameters.
a. Move to the frame that contains the appropriate parameter.
b. Select the parameter that you want and press Enter .
c. Repeat steps a and b for each parameter you want to change.
d. Press Next Screen to access the second screen of parameters.
e. Repeat steps a and b for each parameter you want to change.
f. Press Next Screen again to access the final screen of parameters.
g. Repeat steps a and b for each parameter you want to change.
3. Press Done .
4. You can define another setup function or press Exit Menu to return to the
Ready screen.
When you select a measured parameter to be on, you activate a sensor. Perform a
two-point calibration before you analyze a sample.
Selecting Parameter Units
Use this procedure to select the measurement units that the system displays for each
parameter. Table 5-4 lists the default and optional measurement units that you can
select for the base models and for the base models with a CO-ox module.
Table 5Ć4.āăParameter Measurement Units
Parameter Default Units Optional Units System
pCO
2
, pO
2
mmHg kPa 840, 850, 860
O
2
CT, BO
2
mL/dL mL/L, mmol/L 840, 850, 860
(Continued)
Procedural
Notes
