Bayer HealthCare Rapidlab 800 User Manual
Page 381
4Ć93
Troubleshooting the System
5.
Align the sample connector with the guide pin and slide the “Y” prongs into
the slot at the bottom of the face plate.
The straight path is on top when the CO-ox sample path is disconnected.
6.
Reinstall the screw.
7.
Reconnect the base model sample tubing.
8.
Press
OK
.
To reconnect the CO-ox sample path, turn the CO-ox parameters on, invert the
sample connector. The instructions in the procedure for disconnecting the sample
path describe how to invert the sample connector. When the connector is inverted
and the “Y” is on top, reconnect the CO-ox and base model sample tubing. Press
OK.
Procedural
Notes
