3Ć102 Rapidlab 800 Operator's Manual
Replacing the Measurement Module Lamp
Materials required:
S measurement module lamp
1.
Shut down the system from the Menu screen:
a. Select 7 System Utilities and press Enter .
b. Select 3 Shutdown and press Enter .
c. Press Yes .
CAUTION: You must wait at least 1 minute before you disconnect the power cord,
and then wait at least 10 seconds before you reconnect the power cord. If you do
not adhere to the time intervals, you can damage the system.
2. Wait until prompted, and then disconnect the power cord from the power
source.
3. Disconnect the power cord from the side panel of the system.
4. Turn the system around so that the rear panel faces you.
5. Push the lamp cover up and remove the cover.
WARNING
Ensure that the lamp has been off for at least 5 minutes to allow
sufficient time for it to cool.
6. Allow the lamp to cool for at least 5 minutes.
7. Remove the connector from the system as shown in Figure 3-70.
Figure 3Ć70ā.ăReplacing the Measurement Module Lamp
Bracket
Lamp Cover
Connector
Clamp
Measurement
Module Lamp
7
Menu Code
3
!
