4Ć86
800 Series Operator's Manual
Figure 4Ć19.ā Removing Obstructions from the SpringĆLoaded Latch on an 850
Grasp the tab on the
reference sensor and
pull it up and out of the
measurement module.
Clot-removal
Line
Push the spring-loaded
latch to the right.
d. Connect the measurement module tubing to the latch.
e. Reinstall the reference sensor, ensuring that O-rings are in place.
8.
Press the release tab to close the spring-loaded latch.
9.
Ensure that the sensors are aligned correctly.
10. Close the measurement module door.
11. Press
Continue
.
A wash sequence starts. When the wash sequence finishes, a message box
appears prompting you to perform a two-point calibration.
12. Allow the system to warm up at least 15 minutes.
13. Press
Yes
to perform a two-point calibration.
14. Analyze a minimum of two levels of QC material to verify sensor
performance.
