EĆ2 800 Series Operator's Manual
System Specifications
Table E-1 lists the specifications for the 800 system.
Table EĆ1.āăSystem Specifications
Property Specification
ambient operating
temperature 15 – 32
°
C
ambient operating
relative humidity 5 – 85%, non-condensing
power rating 400VA
voltage requirements 100V/120V (85V to 132V)
50/60Hz
220V/240V (170V to 264V)
50/60Hz
ambient operating
barometric pressure 400 – 825 mmHg (53.0 – 110.0 kPa)
system dimensions,
base model height 50.8 cm (20 inches)
width 55.9 cm (22 inches)
depth 48.3 cm (19 inches)
weight 29.5 kg (65 lbs)
system dimensions,
CO-ox module height 30.3 cm (11.94 inches)
when installed 47.8 cm (18.81 inches)
width 17.35 cm (6.83 inches)
when installed 70.3 cm (27.66 inches)
depth 50.3 cm (19.81 inches)
weight 7.9 kg (17.5 lbs)
when installed 36.5 kg (82 lbs)
