3Ć33 Maintaining the System
4. Reinstall the air filter cover:
a. Align the two pins, located inside the air filter cover, underneath the holes.
b. Push the cover up until it snaps it into place.
5. Press Home to return to the Ready screen.
Replacing the COĆox Air Filter
Materials required:
S CO-ox air filter
1.
Push the air filter cover up until it snaps out and then pull the cover away from
the system as shown in Figure 3-18.
Figure 3Ć18.āăReplacing the COĆox Air Filter
Air Filter Cover
Air Filter
CO-ox Module
2. Remove the old air filter and discard it.
3. Press the new air filter into place.
4. Reinstall the air filter cover:
a. Align the tabs on the cover with the slots in the module.
b. Push the cover up until it snaps it into place.
5. Press Home to return to the Ready screen.
