2Ć50 Rapidlab 800 Operator's Manual
This flag . . . Indicates . . .
↓
the result is below the lower limit of the target range.
↑↑
the result is above the upper limit of the action range.
↓↓
the result is below the lower limit of the action range.
- - -
↑
the result is above the upper limit of the measurement range.
- - -
↓
the result is below the lower limit of the measurement range.
The following table describes the messages that may appear in QC sample reports
on the roll printer:
Message Description
****** = Not in Calibration Sensor is out of calibration.
* = D5 No Endpoint: __ QC sample analysis did not reach endpoint.
↑
or
↓
= exceeds target range QC sample result is above or below the target range.
↑↑
or
↓↓
= exceeds action
range
QC sample result is above or below the action range.
ACCEPTED INTO QC FILE
__ Indicates the QC result status (accepted) and the file
number in which the results are stored.
Bubbles Detected In Sample System detects a non-continuous fluid in the
measurement module sample path.
D2 Excessive Drift: __ Sensor drift is beyond predefined limits during a
one-point or a two-point calibration.
D38 Temperature Error System detects an error in the temperature control
system.
DISCARDED INTO QC
FILE __ Indicates the QC result status (discarded) and the file
number in which the results are stored.
REJECTED INTO QC
FILE __ Indicates the QC result status (rejected) and the file
number in which the results are stored.
