BigIron RX Series Configuration Guide 693
53-1002484-04
Displaying PIM Sparse configuration information and statistics
24
Displaying RP-to-group mappings
To display RP-to-group-mappings, enter the following command at any CLI level.
BigIron RX(config-pim-router)# show ip pim rp-map
Number of group-to-RP mappings: 6
Group address RP address
-------------------------------
1 239.255.163.1 99.99.99.5
2 239.255.163.2 99.99.99.5
3 239.255.163.3 99.99.99.5
4 239.255.162.1 99.99.99.5
5 239.255.162.2 43.43.43.1
6 239.255.162.3 99.99.99.5
Syntax: show ip pim rp-map
This display shows the following information.
Displaying RP information for a PIM Sparse group
To display RP information for a PIM Sparse group, enter the following command at any CLI level.
Syntax: show ip pim rp-hash <group-addr>
The <group-addr> parameter is the address of a PIM Sparse IP multicast group.
This display shows the following information.
This field... Displays...
Candidate-RP-advertisement in Indicates how many seconds will pass before the BSR sends its next RP
message.
NOTE: This field appears only if this BigIron RX is a candidate RP.
RP Indicates the IP address of the Rendezvous Point (RP).
NOTE: This field appears only if this BigIron RX is a candidate RP.
group prefixes Indicates the multicast groups for which the RP listed by the previous
field is a candidate RP.
NOTE: This field appears only if this BigIron RX is a candidate RP.
Candidate-RP-advertisement period Indicates how frequently the BSR sends candidate RP advertisement
messages.
NOTE: This field appears only if this BigIron RX is a candidate RP.
This field... Displays...
Group address Indicates the PIM Sparse multicast group address using the listed RP.
RP address Indicates the IP address of the Rendezvous Point (RP) for the listed PIM
Sparse group.
BigIron RX(config-pim-router)# show ip pim rp-hash 239.255.162.1
RP: 207.95.7.1, v2
Info source: 207.95.7.1, via bootstrap
