Displaying MBGP information
28
Displaying MBGP information
All of the BGP show commands have MBGP equivalents. Use mbgp instead of bgp in the command
syntax. For example, to display the MBGP route table, enter the show ip mbgp routes command
instead of the show ip bgp routes command.
Table 145 lists the MBGP show commands and
describes their output. For information about a command, refer to Chapter 27, “Configuring BGP4
(IPv4 and IPv6)” .
The following sections show examples of some of the MBGP show commands. An example of the
show ip mroute command is also included. This command displays the IP multicast route table.
Displaying summary MBGP information
To display summary MBGP information, enter the following command at any CLI prompt.
Syntax: show ip mbgp summary
NOTE
This command’s display looks similar to the display for the show ip bgp config command. However,
the show ip mbgp config command lists only the MBGP neighbors, whereas the show ip bgp config
command lists only the BGP neighbors.
TABLE 145 MBGP Show commands
Command Description
show ip mbgp summary Displays summary configuration information and statistics.
show ip mbgp config Shows the configuration commands in the running-config.
show ip mbgp neighbors Displays information about MBGP neighbors.
show ip mbgp peer-group Displays information about MBGP peer groups.
show ip mbgp routes Displays MBGP routes.
show ip mbgp < ip-addr>[/ < prefix>] Displays a specific MBGP route.
show ip mbgp attribute-entries Displays MBGP route attributes.
show ip mbgp dampened-paths Displays MBGP paths that have been dampened by route flap
dampening.
show ip mbgp flap-statistics Displays route flap dampening statistics.
show ip mbgp filtered-routes Displays routes that have been filtered out.
BigIron RX# show ip mbgp summary
BGP4 Summary
Router ID: 9.9.9.1 Local AS Number : 200
Confederation Identifier : not configured
Confederation Peers:
Maximum Number of Paths Supported for Load Sharing : 1
Number of Neighbors Configured : 1, UP: 1
Number of Routes Installed : 5677
Number of Routes Advertising to All Neighbors : 5673
Number of Attribute Entries Installed : 3
Neighbor Address AS# State Time Rt:Accepted Filtered Sent ToSend
166.1.1.2 200 ESTAB 0h24m54s 3 0 5673 0
