BigIron RX Series Configuration Guide 323
53-1002484-04
Displaying VLAN information
11
Syntax: show vlan ethernet <slot-number>/<port-number> [| [begin <expression> | exclude
<expression> | include <expression>]
The ethernet <slot-number>/<port-number> parameter specifies a port. The command lists all
the VLAN memberships for the port.
The output shows the following information.
Displaying VLAN status and port types
To display detailed information about the state, port types, port modes, of a VLAN, as well as
control protocols configured on the VLAN, enter the following command.
Syntax: show vlan detail <vlan-id> [| [begin <expression> | exclude <expression> | include
<expression>]
Enter the ID of a VLAN if you want information for a specific VLAN.
TABLE 71 Output of show vlan ethernet
This field... Displays...
Port < slot-number>/ < port-number> is
a member of # VLANs
The number of VLANs a port is a member of.
VLANs The IDs of the VLANs that the port is a member of.
BigIron RX# show vlan e 4/1
Port 4/1 is a member of 2 VLANs
VLANs 1 100
BigIron RX# show vlan detail
Untagged Ports : ethe 2/1 to 2/24 ethe 4/4
Tagged Ports : None
Dual-mode Ports : ethe 3/1 to 3/24 ethe 4/1 to 4/3
Default VLAN : 1
Control VLAN : 4095
VLAN Tag-type : 0x8100
PORT-VLAN 1, Name DEFAULT-VLAN, Priority Level0
----------------------------------------------------------
Port Type Tag-Mode Protocol State
2/1 PHYSICAL UNTAGGED NONE DISABLED
2/2 PHYSICAL UNTAGGED NONE DISABLED
2/3 PHYSICAL UNTAGGED NONE DISABLED
2/4 PHYSICAL UNTAGGED NONE DISABLED
2/5 PHYSICAL UNTAGGED NONE DISABLED
.
. (output edited for brevity)
.
4/1 PHYSICAL UNTAGGED NONE FORWARDING
4/2 PHYSICAL UNTAGGED NONE FORWARDING
4/3 PHYSICAL UNTAGGED NONE FORWARDING
4/4 PHYSICAL UNTAGGED NONE DISABLED
PORT-VLAN 100, Name [None], Priority Level0
----------------------------------------------------------
Port Type Tag-Mode Protocol State
4/1 PHYSICAL TAGGED STP FORWARDING
4/2 PHYSICAL TAGGED STP BLOCKING
