BigIron RX Series Configuration Guide 245
53-1002484-04
Deploying a LAG
8
Commands available under LAG once it is deployed
Once a LAG has been deployed, the following configurations can be performed on the deployed
LAG:
• Configuring ACL-based Mirroring
• Disabling Ports within a LAG
• Enabling Ports within a LAG
• Monitoring and Individual LAG Port
• Assigning a name to a port within a LAG
• Enabling sFlow Forwarding on a port within a LAG
• Setting the sFlow Sampling Rate for a port within a LAG
Configuring ACL-based mirroring
ACL-based mirroring can be configured for an individual port within a LAG using the acl-mirror-port
command, as shown in the following.
BigIron RX(config)# lag blue static
BigIron RX(config-lag-blue)# deploy
BigIron RX(config-lag-blue)# acl-mirror-port ethe-port-monitored 3/1
Syntax: [no] acl-mirror-port ethe-port-monitored <slot/port> | named-port-monitored <name>
Use the ethe-port-monitored option with the appropriate <slot/port> variable to specify a Ethernet
port that you want to provide ACL mirroring for.
Use the named-port-monitored option with the appropriate <slot/port> variable to specify a named
port that you want to provide ACL mirroring for.
NOTE
Mirror (analyzer) ports cannot be assigned to the 16x10G card. You can monitor traffic on 16x10
ports.
Disabling ports within a LAG
You can disable an individual port within a LAG using the disable command within the LAG
configuration as shown in the following.
BigIron RX(config)# lag blue static
BigIron RX(config-lag-blue)# deploy
BigIron RX(config-lag-blue)# disable ethernet 3/1
Syntax: [no] disable ethernet <slot/port> | named <name>
Use the ethernet option with the appropriate variable to specify a Ethernet port within
the LAG that you want to disable.
Use the named option with the appropriate <name> variable to specify a named port within the
LAG that you want to disable.
