Hardware 2-19

Octel Overture 200/300 Serenade 3.0

PB60014–01

Each LIC contains the necessary circuitry for ring detection, dial tone detection, and signal power
measurement, allowing automatic gain control from 0 dB to 24 dB of gain for recording messages.
The LIC contains a yellow LED for each port, which indicates port activity.

In the Octel Overture 200, line cards can occupy slots A1 through A6.

In the Octel Overture 300, line cards can occupy slots A1 through A11.

Telemarketing Line Card (TLC)

The telemarketing line card is an 8-port line card. It differs from the LIC, because only the first port
of the TLC located in slot A1 can be used for recording. The seven remaining ports of the TLC in
slot one are play-only ports. All other TLC ports in the message server are play-only ports. When
recording is attempted on other ports, the Octel Overture 200/300 prompts “Messages may not be
recorded at this time. No storage is available.”

The first TLC must be installed in slot A1. Standard line cards can be installed in slots beyond the
TLC cards. The TLC is FCC part 68 registered.

In the Octel Overture 200, the TLC can occupy slots A1 through A6.

In the Octel Overture 300, the TLC can occupy slots A1 through A11.

Direct Access Card (DAC)

The direct access card (DAC) is an optional, 4-port interface card. When used in place of the standard
LIC, the DAC allows the direct connection of incoming DID or outgoing PBX trunks. The DAC
requires an external –48-Vdc PSU and a rear-mounted DID I/O panel.

In the Octel Overture 200, the DAC can occupy slots A1 through A6.

In the Octel Overture 300, the DAC can occupy slots A1 through A11.

EntryWorks ACP Card

The EntryWorks ACP card is the application control processor for the Works for Serenade flow
control language. It includes the host interface and the ACP SCSI disk drive control.

In the Octel Overture 200, the EntryWorks ACP must occupy slot A7.

In the Octel Overture 300, the EntryWorks ACP must occupy slot A12.

EntryWorks also requires the following:

-

EntryWorks disk drive

-

EntryWorks serial I/O panel and cable

-

EntryWorks external modem and cable
