8-16
Installation and Maintenance Volume
Octel Overture 200/300 Serenade 3.0
PB60014–01
Table 8-2 Hardware Error Types and Remedies (continued)
Error Type:Name
Priority
Remedy
Source
34. Power-ON
Diagnostic Error
Selftest for line cards.
Replace LIC as indicated by slot number.
2
For LIC4
For LIC 8, TLC 8
DATA-1 =
PORT 1
DATA-1 =
PORT 1, PORT 2
DATA-2 =
PORT 2
DATA-2 =
PORT 3, PORT 4
DATA-3 =
PORT 3
DATA-3 =
PORT 5, PORT 6
DATA-4 =
PORT 4
DATA-4 =
PORT 7, PORT 8
Error Codes for all DATA values:
00 =
NO ERRORS DETECTED
01 =
CHANNEL STATUS REGISTER ERROR
02 =
CVSD DATA REGISTER BIT/ADDRESS ERROR
04 =
A/D CONVERTER OR POWER DETECT ERROR
08 =
CVSD ENCODING CIRCUIT ERROR
10 =
DTMF SENDER, POWER LIMITER ERROR
20 =
CVSD DECODING CIRCUIT OR OUTPUT GAIN CIRCUIT ERROR
40 =
CVSD DECODING, ENCODING ERROR
80 =
DTMF SENDER, DTMF DECODER ERROR, OR BAND PASS FILTER
CIRCUIT ERROR
FF =
FATAL ERROR
34 Power-ON Diag-
nostic Error
Selftest for integration
cards.
TE INT
LI INT
DATA-1 through
DATA-4 designate
errors found.
Replace integration card as indicated by
slot number.
2
DATA-1:
Bit 5:
TIMER
Bit 4:
NMI
Bit 3:
Incorrect checksum fond in code during normal operation
Bit 2:
Normal (error found during normal code operation)
Bit 1:
BOOT (error found during boot process)
Bit 0:
Incorrect checksum found in code during boot process
