Procedures 12-43

Octel Overture 200/300 Serenade 3.0

PB60014–01

An explanation of the entries in the display follows.

-

Slot. Slot number for which status is given. The alphabetic character identifies the Octel Overture 200/300
shelf; the numeric character identifies the slot number.

Octel Overture 200

Octel Overture 300

System 1

System 1

System 2

System 2

Voice 1

Voice 1

Voice 2

Voice 3

Voice 4

-

Type. Identifies the type and sequence of the drive slots, as one of the following:

-

ID. Identifies the type and sequence of the disk drives, as previously recorded on the drive itself. When
physically installed in the correct slot, the drive appears as

Octel Overture 200

Octel Overture 300

S1

S1

S2

S2

V1

V1

V2

V3

V4

-

Status. Gives the status of the drive, as one of the following:

Active

Valid

Invalid

Unknown

Illegal

Error

Empty

Refer to the status entry explanations in the

DSKMAP

section of this chapter.

-

Configured. Identifies the drive as one of the following:

-

Configured — Drive is within the number of drives currently configured.

-

Not Configured — Drive is not being utilized as its position is greater than the number of drives currently
configured.

DISKO

The

DISKO

utility, available when the Octel Overture 200/300 is booted from floppy software using the Update

diskettes, prepares the message server for

-

Adding a disk

-

Removing a disk

-

Replacing a disk
