2-14

Installation and Maintenance Volume

Octel Overture 200/300 Serenade 3.0

PB60014–01

Subsystem Configurations

The following tables list each subsystem name, abbreviation, part number, and a brief description.
Table 2-1 lists subsystems that are interchangeable between the Octel Overture 200 and the Octel
Overture 300 message server. Table 2-2 lists subsystems for the Octel Overture 200 message server
and Table 2-3 lists subsystems for the Octel Overture 300 message server. Following the last table
are more complete descriptions of the subsystems.

Table 2-1 Octel Overture 200/300 Subsystems

Subsystem Configurations

Part Number

Description

STORAGE

500-MB Storage Drive

Overture 200 – 37/46 hours*
Overture 300 – 31/46 hours*

1.0-GB Storage Drive

Overture 200 – 87/96 hours*
Overture 300 – 81/96 hours*

2.0-GB Storage Drive

Overture 200 – 176/185 hours*
Overture 300 – 170/185 hours*

740-6632-002

740-6631-002

740-6633-002

Capacity on Demand (COD), 0 hour drives.
SCSI hard disk drives for storage of voice
messages, prompts, system configuration data,
and software.

* The capacity is for message server overhead
and one language (slots 1 and 2) and full
capacity (slots 3–6). Subtract 1.2 hours for each
additional language.

LINE INTERFACE CARDS (LIC)

United States, Canada,
Mexico

300-6002-001

4-port, two-wire, loopstart telephone line
interface card (LIC4); 4 ports authorized.

300-6032-001

8-port, two-wire, loopstart telephone line
interface card (LIC8); 8 ports authorized.

300-6054-001

16-port, loopstart telephone line interface card
(DLC16); 0 ports authorized.

United Kingdom

300-6002-002

4-port, two-wire, loopstart telephone line
interface card; 4 ports authorized.

300-6032-002

8-port, two-wire, loopstart telephone line
interface card; 8 ports authorized.

300-6056-002

12-port, loopstart telephone line interface card
(ILC12); 0 ports authorized.

300-6054-002

16-port, telephone line interface card; 0 ports
authorized.

France, Belgium

300-6044-001

4-port, two-wire, loopstart telephone line
interface card; 4 ports authorized.

300-6054-017

16-port, loopstart telephone line interface card
(DLC16); 0 ports authorized.
