Installation 4-13

Octel Overture 200/300 Serenade 3.0

PB60014–01

Figure 4-4 Octel Overture 300 Direct-Connect Installation

DC Filter Assembly

Positive Lead

Negative Lead

Cover

Terminal Block

Ground Lead

Conduit Strain Relief

1/2Ćinch Diameter Conduit
