11B-10

Installation and Maintenance Volume

Octel Overture 200/300 Serenade 3.0

PB60014–01

SNMP Trap CP Trace Example

Following is an example of a CP trace for an SNMP trap:

MM/DD/YY HH:MM:SS PRT TYPE EVENT AUX MBX/EXTN MSG# SL U L SOURCE
D1 D2 D3 D4 D5

05/18/94 12:06:08 LAN_OUT SNMP_TRAP 001

The value 001 (currently the only one defined) in the auxiliary field (AUX) indicates that the SNMP trap
is being sent because of a hardware error.

Hardware Error Table Entries for an SNMP Trap

A hardware error type 42, DATA1 = 17(hex) will be logged if a trap needs to be sent but the SNMP
system manager is not known. For example,

@L H

THU 05/19 09:13:17 1994 ABC,INC ID:123456 S/N:123456 PBX:23

CLEARED: 05/19 09:10

TYPE SLOT CHNL PRIO DATE TIME #BAD DATA1 DATA2 DATA3 DATA4

42 06 00 1 05/19 09:13 1 00000017 00000000 00000000 00000000

For the SNMP manager system to be configured, either its IP address (System Parameter 235) or its host
name (System Parameter 236) and the IP address of the domain name server (System Parameter 233)
must be known.

Once an SNMP trap has been generated, the

L H

command displays this information. For example,

@L H

THU 05/19 13:22:08 1994 ASKME ID:123456 S/N:123456 PBX:23

CLEARED: 05/19 12:51

*** SNMP MANAGER SYSTEM HAS BEEN NOTIFIED ***

TYPE SLOT CHNL PRIO DATE TIME #BAD DATA1 DATA2 DATA3 DATA4

33 01 00 3 05/19 12:54 1 00000000 00000003 00000002 00000000
64 06 00 3 05/19 13:01 1 00000002 00000001 00000000 00000000

After successful completion of an

SNMP TEST

, hardware error type 64, DATA1 = 0E(hex) with a

priority of 0 is logged.
