6-38
Installation and Maintenance Volume
Octel Overture 200/300 Serenade 3.0
PB60014–01
Figure 6-1 Alarm Test Flow
@L H
FRI MM/DD HH:MM:SS YYYY SYSTEM NAME ID:XXX S/X:XXX PBX:XXX
CLEARED: MM/DD HH:MM
***ALARM HAS BEEN GIVEN***
TABLE IS EMPTY
Callout feature tested
or
@
C H
PRESS
PRESS
PRESS
*
#
#
Goodbye
CONNECT
Modem and Terminal
DISCONNECT
@
TE A
Acknowledged
Stop call
Logon for
remote access
Line beeps" for up
to 3 minutes
List Hardware
Error Table
Clear Hardware Error Table
Beep, beep, beep. This is an alarm from
number 123. Error Type O has occurred. Press
star to confirm or press pound for modem
access."
Call disconnects after1 minute.
Message server retries call every 10
minutes, until acknowledged.
Alarm Callout enabled
Not
Acknowledged
Message server calls string entered in System Parameter 31
