10-2 Installation and Maintenance Volume
Octel Overture 200/300 Serenade 3.0 PB60014–01
Card
Ejector
Card Stiffener
Status
LEDs
Card Ejector
Figure 10-1 DTIC Component Layout
Card Stiffener
Power/run
LEDs
Connector P3 Connector P2 Connector P1
Connector
P4
WDT
jumper
DSP
PGA
DSP
memory
DSP
DSP
PGA
DSP
memory
DSP
DSP
PGA
DSP
memory
DSP
DSP
PGA
DSP
memory
DSP
DSP
PGA
DSP
memory
DSP
Reserved
for 6th
DSP
PGA
DSP
memory
DSP
CP memory PGA
SM
Boot
ROM
Trunk
Framer
Trunk
Framer
sw2
75 ohm 120 ohm
sw1
75 ohm 120 ohm
