Hardware Replacement 9-43
Octel Overture 200/300 Serenade 3.0 PB60014–01
Figure 9-24 Power-Filter Assembly for 120-Vac and 240-Vac Domestic Octel Overture 300
Connector
Mounting
Screws
PowerĆFilter
Assembly
HarnessĆGrounding
Hardware
BackplaneĆtoĆ
Filter Harness
Front Viewof
Connector
Green/Yellow
Brown
Blue
Connector
