8-18 Installation and Maintenance Volume
Octel Overture 200/300 Serenade 3.0 PB60014–01
Table 8-2 Hardware Error Types and Remedies (continued)
Error Type:Name Priority Remedy Source
34. Power-ON
Diagnostic Error
Selftest for CPU.
DATA-1 through
DATA-4 designate
errors found. Replace CPU. For OCC error, replace
OCC. 3
DATA-3
Bit 7: TDM crosspoint error
Bit 6: Modem failure
Bit 5: COM port failure
Bit 4: Watch Dog Timer failure
Bit 3: OCC error
Bit 2: Floppy Disk Controller error
Bit 1: Real Time Clock error
Bit 0: DMAC error
DATA-4
Bit 3: CODEC failure
Bit 2: BIC error
Bit 1: VCU error
Bit 0: Control Bus error
34: Power-ON
Diagnostic Error
Selftest for VCU.
DATA-1 through
DATA-4 designate
errors found Replace VCU. 3
DATA-1
Bit 0: Control Memory parity error detected in memory test.
Bit 1: Control Memory parity circuit failed.
Bit 2: Unexpected interrupt was received.
Bit 3: Timer A interrupt not detected or Timer A timing error detected.
Bit 4: Timer B timing error detected.
Bit 5: Timer C timing error detected.
Bit 6: Timer D timing error detected.
Bit 7: Byte Clock A circuit error detected.
DATA-2
Bit 0: Byte Clock B circuit error detected.
Bit 1: Voice memory failed memory test.
Bit 2: Voice Memory refresh circuit error detected.
Bit 3: Voice Memory parity circuit failed.
Bit 4: Write Protect Memory failed memory test.
Bit 5: Write Protect functionality failed.
Bit 6: Control Bus Shared Memory error detected.
Bit 7: Port Controller Memory failed memory test.
