8-32 Installation and Maintenance Volume
Octel Overture 200/300 Serenade 3.0 PB60014–01
Table 8-2 Hardware Error Types and Remedies (continued)
Error Type:Name Priority Remedy Source
64. LAN Card
Hardware Error
(continued)
Problem detected by
the LAN card. Dependent on the DATA-1 values described
below. 3
B = CONTROL BLOCK SIZE MISMATCH
Compatibility problem with LAN card.
DATA-2 = LOW BYTE OF CTL BLOCK SIZE
REMEDY: Contact your technical support center.
C = CPU DATA PACKET RECEIVED GOT CHECKSUM ERROR
Data communication is being corrupted between the current system
CPU and the CPU at the location specified.
DATA-2 values as follows:
1 On open conn request received
2 On connless data packet
3 On data packet received
4 On connection grant received
5 On connection reject received
6 On a query packet received
7 Remote end had the cksum error
DATA-3 = LOW BYTE OF LOCATION
DATA-4 = UPPER BYTE OF LOCATION
REMEDY: The LAN card guarantees that if a packet gets through, it
should be perfect, regardless of line conditions.
Therefore, this most likely points to the software on
either the CPU or LAN card. Was the software recently
changed or upgraded at either location? If this continues,
contact your technical support center.
To determine the other location: Subtract 2 from the
number in Data-2 and Data-3 to get the location number
starting from 1. In
UPDATE , list the LOCATION T able to
determine the name of the corresponding location.
65 DMA Channel
Error
Problem with CPU
card Replace CPU card 2
66. LAN Card
Reported
Hardware Error
Problem detected by
the LAN card. Dependent on the DATA-1 values as
described below. 3
DATA-1 = ERROR CODE ON LAN CARD:
01 = ERROR LOGGED PRIOR TO SYNC-UP WITH CPU
REMEDY: Contact your technical support center.
