Installation 4-25

Octel Overture 200/300 Serenade 3.0

PB60014–01

12-Port International Line-Interface Card

The following pin assignments are for the 12-port international line-interface card (ILC12) as they appear
on the rear 50-pin telco connector.

50-Pin Number

Signal Function

50-Pin Number

Signal Function

1

RING1

26

TIP1

2

RING2

27

TIP2

3

RING3

28

TIP3

4

RING4

29

TIP4

5

RING5

30

TIP5

6

RING6

31

TIP6

7

RING7

32

TIP7

8

RING8

33

TIP8

9

RING9

34

TIP9

10

RING10

35

TIP10

11

RING11

36

TIP11

12

RING12

37

TIP12

13

38

14

39

15

40

16

41

17

42

18

43

19

44

20

45

21

46

22

47

23

48

24

49

25

50
