4-12

Installation and Maintenance Volume

Octel Overture 200/300 Serenade 3.0

PB60014–01

Figure 4-3 Octel Overture 200 Direct-Connect Installation

Terminal Block

Negative Lead

Positive Lead

Cover Plate

Conduit Strain

Relief

12Ćinch Diameter

Conduit

DC Inlet Box

Ground

Lead
