Operating Parameters (4/8)
Oven #1 Vent #1
> - Carrier gas number 1-1
- Vent type
BF
- Vent fl owrate 30 +/-5
Menu Menu Menu Menu Oven# Gas#
F1 F2 F3 F4 F5 F6
11/03/22
15:15:45
Operating Parameters (5/8)
> - Pressure unit kPa
- Vent fl owrate unit ml/min
- Sample volume unit μl
Menu Menu Menu Menu Oven# Gas#
F1 F2 F3 F4 F5 F6
11/03/22
15:15:45
Operating Parameters (6/8)
Oven #1 Valve #1
- Valve type Other
- Sample phase Liquid
- Sample pressure 300
- Sample fl owrate 10
- Sample volume 0.33
Menu Menu Menu Menu Oven# Valve#
F1 F2 F3 F4 F5 F6
Figure 1.10 Example of the operation condition confi guration screen of the GC-HMI (touch panel)
EtherLCD
(4) Isothermal Oven
A large isothermal oven (volume: 40 L) and isothermal oven (31 L) are provided, each having a
pressurized enclosure.
The temperature setting of both ovens is the fi xed set point. The setting range is from 55 to
225°C (in 1°C units). When LSV is equipped, the temperature is set at a fi xed value from 60 to
250°C (in 1°C units). When FPD is equipped as a detector (only for the large isothermal oven),
the temperature is set at a fi xed value from 0 to 60°C (in 1°C units).
