<5. EtherLCD>
5-72
IM 11B08A01-01E
4. Copy rules for synchronized peaks.
Destination
Source
Independent peak Parent peak Child peak
Independent peak Copy as is (change copy
item)
Maintain destination peak
in independent peak and
synchronize (comply with
synchronization rules to
change synchronization
items).
Assess using peak
synchronizing rules. When
synchronization is not possible,
maintain independent peak
and synchronize. When
synchronization is possible,
set synchronization as
synchronization target of copy
destination = synchronization
target of copy source.
Parent peak Cannot copy Cannot copy Cannot copy
Child peak Convert to independent
peak and copy (change
copy item).
Convert to independent
peak and synchronize
(comply with
synchronization rules to
change synchronization
items).
Assess using peak
synchronizing rules. When
synchronization is not possible,
maintain independent peak
and synchronize. When
synchronization is possible,
set synchronization as
synchronization target of copy
destination = synchronization
target of copy source.
5. Copy items: Copy stream number in peak process-specifi c setup part (T19) and parts other
than relative peak number
 Peak copy 2
Press F3 (Copy 2).
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Peak Copy 2 (1/2)
Stream # 1 Use num # 1 Assign # 10
Peak# Name Usage Process (Detail)
1 P1
On Base level
2 Off Indirect
3 Off Indirect
4 Off Indirect
5 Off Indirect
6 Off Indirect
7 Off Indirect
8 Off Indirect
Menu PeakSet Copy
F1 F2 F3 F4 F5 F6
Figure 5.80 Example of peak copy 2 screen
F1 (Menu): Displays the Table Menu screen.
F2 (PeakSet): Displays the Peak Setup-Specifi c screen
F6 (Copy):
Executes copy after entering Source peak and Destination peak.
• Stream number for display and setting becomes the stream number in the peak setup-
specifi c screen when relevant screen is requested.
• Copy destination peak must be an independent peak.
• See Peak synchronization and peak copy items regarding data for copy.
• When Process (Type) is set to No processing, Process (Detail) displays No processing.
2nd Edition : May 11, 2012-00
