<5. EtherLCD>
5-43
IM 11B08A01-01E
F1 (Menu): Displays the Table Menu screen.
F5 (Oven #): Specifi es an oven number.
F6 (Det #):
Specifi es a detector number.
TIP
• The oven numbers set to Not provided on the Temperature Control Set cannot be selected.
• The detector numbers set to Not provided on the Detector Set screen cannot be selected.
• The initial screen displays the smallest oven number among those assigned to isothermal
ovens on the Temperature Control Set.
Display Item Name Set Lower Limit Upper Limit Unit Remarks
Oven # Oven number 1 3
Det # Detector number 1 2
Carrier gas
number
Carrier gas number ---
1-1
1-2
2-1
2-2
3-1
3-2
* --- indicates not used.
Vent-D fl ow
rate
○ Alpanumeric: 10 characters
* The detector type is
displayed.
TCD/FID/FID-MC/FPD
Detector type None
TCD
FID
FID-MC
FPD
Vent-REF ○ Alpanumeric: 10 characters
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Operating Parameters (4/8)
Oven # 1 Vent # 1
> - Carrier gas number - - -
- Vent type - - -
- Vent fl owrate
Menu Oven# Vent#
F1 F2 F3 F4 F5 F6
Figure 5.56 Example of the operating parameters screen (4/8)
F1 (Menu): Displays the Table Menu screen.
F5 (Oven #): Specifi es an oven number.
F6 (Vent #):
Specifi es a vent number.
TIP
• The oven numbers set to Not provided on the Temperature Control Set cannot be selected.
• Only carrier gas numbers for which a gas type is set on the Operation Parameters screen (1/8) can be
selected.
2nd Edition : May 11, 2012-00
