<1. Overview>
1-11
IM 11B08A01-01E
Desk-top type
• Converter for RS-422/RS-232C: K9806AT
• Signal interrupter for Ethernet twisted pair cable: K9806AB
135
90
15
38
41.5
Unit: mm
The number and the location of
the terminals depend on its part number.
Note: Desk-top type should be installed horizontally.
Converter for Ethernet/SHDSL: K9802PB (to be announced)
(AC) SHDSL DI
N L
ERR USB PWR
LINK CPE CO
20
41 46
120
170
185
201
96 11
0
Unit: mm
4-holes for M4 screw
Power supply 100 to 240V AC
2nd Edition : May 11, 2012-00
