<5. EtherLCD>
5-100
IM 11B08A01-01E
• Data acquisition peak 1 to 8
Set peak number of the cal run stream to acquire data used to compile a SimDis calib curve.
• Elapsed Time 1 to 8, Standard B.P. 1 to 8
Curve data of a SimDis Calib curve. Auto updating and manual entry are possible.
• When GCM cal run stream set to Yes for calib curve updating on the SimDis Setup screen
is executed, the peak retention time acquired by executing cal run stream and Standard B.
P. data on the corresponding peak set-up specifi c screen are used to calculate time date
beyond Elapsed Time 6 set in the SYS method (from cal setup screen the corresponding
stream number can identify SYS method number) to update the calib curve coef a and the
calib curve coef b. Again, the retention time acquired through the activated cal run stream
is set to Elapsed Time and the standard B.P. set in Peak Setup-Specifi c is updated to the
Standard B.P.
When F5 (SYS #) is pressed, “SYS Number:” is displayed on the second line below. Use the
numeric keypad to enter the number and press the SET/ENT key, and a cursor jumps to the SYS
number. However, only SYS numbers set in GCM are selectable, when any other number is
entered, “Over limit” is displayed on the second line below.
F6 (Method #): Specifi es a Method number.
Display Item Name Set Lower Limit Upper Limit Unit Remarks
GCM # GCM Number
SYS # SYS Number ○
Method # Method number ○
Data acquisition
stream
○ 0 31
Calib curve coef a ○ −9.999 9.999
Calib curve coef b ○ −999.999 999.999
Data acquisition
peak 1 to 8
○ 0 999
Elapsed Time1 to 8 ○ 0.0 21600.0
Standard B.P.1 to 8 ○ −9999.9 9999.9
5.4.26 User Setup (User Defi ned)
1 1 / 1 1 / 2 2
1 5 : 1 5 : 4 5 Units Setup (User Defi ned)
Unit # 21
>
- Unit name aaaaaaaa
Menu Unit#
F1 F2 F3 F4 F5 F6
Figure 5.113 Example of User Setup (User Defi ned) screen
F1 (Menu): Displays the Table menu screen.
F6 (Unit #): Enters User defi ned unit numbers.
Display Item Name Set Lower Limit Upper Limit Unit Remarks
Unit # User defi ned unit
number
21 100
Unit Name Unit name ○ 8 one-bite alphanumeric
characters
